ST775GCDP03R51 Turbine Air Starter by Ingersoll Rand

ST775GCDP03R51 Turbine Air Starter by Ingersoll Rand

SKU:: ST775GCDP03R51
UPC:

Price: $4,329.11

Current Stock:

Quantity:

Get Our BEST Pricing FAST - click below

Click Here to get an air starter quote FAST!

Our Phone #: 1-800-353-4676

Our Email: [email protected]

Description

Description

The Ingersoll Rand ST775GCDP03R51 is a genuine IR ST700-series pre-engaged turbine air starter. The ST775 designation does not appear in Ingersoll Rand's published catalogs; IR's supersession list shows ST775 models as "call for supersession". This part number decodes as a C-ratio, pre-engaged ST700-family starter with an SAE No. 3 flange and a right-hand 15-tooth 6/8 pitch pinion. Call us for the exact specification and for the current ST1000-series replacement.

ST775GCDP03R51 Specifications

Ingersoll Rand ST775GCDP03R51 technical data
Manufacturer / series	Ingersoll Rand ST700 family (ST775)
Engagement	Pre-engaged
Gear ratio	"C" gearing
Mounting	SAE No. 3 flange
Pinion (code 51)	15 teeth, 6/8 pitch, right-hand
Rotation	right-hand (R)
Status	ST775 not listed in IR's published catalogs; call for specifications

Confirming Fit

Match the full model number on your existing starter's nameplate, or send us the engine make, model and serial number. You can also use our Air Starter Model Finder.

How to Read the Model Number

Code	Meaning
ST7	ST700 series turbine starter
75	Percent arc: 75% (half arc, 90 to 150 psi)
G	Gas sealed
C	Gear ratio 2.53:1 (B = 2.18:1, C = 2.53:1)
D	Type of gear case
P	Pre-engaged (I = inertia)
03	SAE No. 3 flange (09 = IR "09" flange for D ratio)
R	right-hand rotation
51	Pinion: 15-tooth 6/8 pitch

Why Choose the ST775GCDP03R51?

High torque, broad range. B and C gearing options cover a wide range of starting torques.
Lube-free turbine. No lubricator and no oil mist; sealed planetary gears are maintenance free.
Air or natural gas. Sealed for gas and air applications.
Proven design. The ST700/900 turbine family has powered diesel and gas engines in marine, oil and gas, locomotive and power generation service.
Current replacement available. Ingersoll Rand's ST1000 series is the direct successor.

ST775GCDP03R51 FAQ

What is the opposite-rotation version of the ST775GCDP03R51?

The ST775GCDP03L52 is the opposite-rotation counterpart. Power, flange and gearing are the same; only the rotation and the matching pinion code differ. Match the rotation printed on your existing starter's nameplate.

Is this starter still available, and what replaces it?

Ingersoll Rand's ST1000 series supersedes the ST700 and ST900 (the ST750 and ST950 go to the ST1060, and the ST799 and ST999 go to the ST1099, with the same ratio, drive, flange and pinion). Call us and we will confirm current availability of the ST775GCDP03R51 and quote the ST1000 alternative side by side. See the ST1000 series.

Can it crank for a long time?

Ingersoll Rand does not rate the ST750 and ST799 for extended cranking (more than 10 seconds). If your engine needs long crank cycles, choose an ST900-series or ST1000-series starter.

What air supply and accessories does it need?

Supply 90 to 150 psi through a 1-1/2 in. line, with enough receiver volume to deliver up to 1,300 scfm while the engine cranks. Ingersoll Rand's matching accessories include the SRV150 relay valve (SRV150SS for gas), the ST900-267-24 1-1/2 in. strainer (300 mesh), 150BMP-1051B / 150BMP-2451B solenoid valves and SMB-618 / SMB-G618 push-button valves.

Buy from a Factory-Authorized Ingersoll Rand Distributor

AirStartersDirect.com is a factory-authorized Ingersoll Rand distributor operated by Zampini Industrial Group, which has supplied engine starting equipment since 1987. Every ST775GCDP03R51 we sell is new, genuine Ingersoll Rand equipment. We supply the ST700 and ST900 series, the current ST1000 series, and the relay valves, strainers and tune-up kits that go with them.

Need help confirming fit? Call 1-800-353-4676 with your engine make, model and serial number for a fast quote and free selection help.

Specifications source: Ingersoll Rand Engine Starting Systems catalog and Ingersoll Rand ST900 Series Air Starters.

Ingersoll Rand pneumatic air starters can replace any factory mounted starter engine and simultaneously offer a variety of helpful benefits. Compared to conventional electric starters, a pneumatic air starter occupies considerably less space as it is run by air. Pneumatic air starters are also considered safer in hazardous environments as they do not produce electrical sparks like electric starters sometimes do, thus eliminating the risk of igniting flammable materials that may be present.

Ingersoll Rand air starters have significantly more torque than electric starters of equivalent size, and that allows even a small air starter to start very large engines and turbines. In addition, electric starters as well as their wiring may become excessively hot in the event that it takes longer than expected to start the engine, while air-starters can be run for as long as their air supply lasts. Turbine starters provide even more torque and tend to be simpler, and therefore are a natural fit for turbine engines. Turbine air starters are utilized extensively on large turbofan engines commercial and military aircraft; as well as marine ships and vessels, trains, heavy construction equipment, and more.
